The AES-15 vessel forms the core of a robust, low maintenance and highly reliable Seal Support System. The vessel is constructed from 316 stainless steel and is designed to meet the high-end needs of the chemical, pharmaceutical and petrochemical industries. A cooling coil is supplied as standard with the vessel. The AES-15 can operate at pressures up to 30 bar/435psi and temperatures up to 100°C/212°F. Both oil and water can be used as barrier fluids with the AES-15, ensuring its compatibility with a wide range of industrial pump applications.
- Designed and manufactured in accordance with ASME V III Div 1 and PED 97/23/EC
- 316 SS vessel and weld pad construction
- Integral cooling coil as standard
